The 2.5-liter Toyota 2VZ-FE engine was assembled from 1988 to 1991 at the concern’s American plant and was installed only on the popular Camry Prominent sedans and its analogue Lexus ES 250. Constant problems with overheating forced the manufacturer to soon withdraw it from production.
VZ family: 1VZ-FE, 2VZ-FE, 3VZ-E, 3VZ-FE, 4VZ-FE, 5VZ-FE.
Specifications
| Production years | 1988-1991 |
| Displacement, cc | 2507 |
| Fuel system | MPI |
| Power output, hp | 159 |
| Torque output, Nm | 216 |
| Cylinder block | cast iron V6 |
| Block head | aluminum 24v |
| Cylinder bore, mm | 87.5 |
| Piston stroke, mm | 69.5 |
| Compression ratio | 9.0 |
| Features | no |
| Hydraulic lifters | no |
| Timing drive | belt |
| Phase regulator | no |
| Turbocharging | no |
| Recommended engine oil | 5W-30 |
| Engine oil capacity, liter | 3.9 |
| Fuel type | petrol |
| Euro standards | EURO 1/2 |
| Fuel consumption, L/100 km (for Lexus ES 250 1991) — city — highway — combined |
12.4 8.4 10.6 |
| Engine lifespan, km | ~250 000 |
| Weight, kg | 195 |
The engine was installed on:
- Toyota Camry 2 (V20) in 1988 – 1991;
- Lexus ES250 1 (V20) in 1989 – 1991.
Disadvantages of the 2VZ-FE engine
- Often in these engines, the cylinder head cracked as a result of a gasket breakdown.
- Often the culprit of overheating was an unreliable fan hydraulic drive.
- There is increased wear on the crankshaft journals and connecting rod bearings.
- Spare parts for this engine are very difficult to find and they are very expensive.
- Also in the minuses we will add a high fuel consumption and a progressive oil burner.
Frequently asked questions about the Toyota 2VZ-FE
How much power does the Toyota 2VZ-FE make?
The Toyota 2VZ-FE develops 159 hp and 216 Nm of torque.
How much oil does the Toyota 2VZ-FE take and which one?
Engine oil capacity: 3.9 liters. Recommended oil: 5W-30.
Does the Toyota 2VZ-FE have a timing belt or chain?
The Toyota 2VZ-FE uses a timing belt.
Is the Toyota 2VZ-FE turbocharged?
No, the Toyota 2VZ-FE is naturally aspirated.
Does the Toyota 2VZ-FE need valve clearance adjustment?
Yes, there are no hydraulic lifters, so the valve clearances have to be checked and adjusted periodically.
How long does the Toyota 2VZ-FE last?
The typical lifespan of the Toyota 2VZ-FE is ~250 000 km with proper maintenance.
What is the fuel consumption of the Toyota 2VZ-FE?
Lexus ES 250 1991: city 12.4, highway 8.4, combined 10.6 L/100 km.
What cars was the Toyota 2VZ-FE installed on?
Toyota Camry 2 (V20) in 1988 - 1991; Lexus ES250 1 (V20) in 1989 - 1991.
What are the common problems of the Toyota 2VZ-FE?
Often in these engines, the cylinder head cracked as a result of a gasket breakdown. Often the culprit of overheating was an unreliable fan hydraulic drive. All known problems.
